71 017-882-B0-001 Rev. C2 (10/2013)
3.0
Operation
3.4.2 Applications
There are currently six applications:
1. Configuration Logging
2. Alarm Event Logging
3. Battery Information Logging
4. Utility Performance
5. Battery Health
6. Battery Run Time
Press ENTR to access the CONFIG HISTORY
screen. The “CL” indicates that this is a
Configuration Log record, and the time stamp
shows when the record was created. Lines
two and three on the display contain the record
contents. In this example, the APP firmware
version record is shown.
The screen will begin with the most recent
record created. Press the down( ↓) softkey to
view earlier records, or press the up( ↑) softkey
to view more recent records.
AlphaAPP V1.05.0
C ONFIG HISTORY
APPS CONFIG
ENTR ESC
Configuration Log Screen:
To enter the Configuration History screen, scroll
up or down until the CONFIG HISTORY is at
the top of the scroll area.
CL 03/19/11 03:21:22
AlphaAPP V1.00.0
ESC
3.4 AlphaAPPs Overview, continued
3.0 Operation, continued
