2.2.12 Navigating the Web Page
2.0
Installation, continued
Once the Web page has been successfully accessed, the operator is able to select a link on the
header bar and the page specific to the topic will open enabling real-time data to be observed.
See Fig. 2-35 for DSM3 Series navigation bar items.
Fig. 2-35, DSM3 Series Navigation Bar Items
Commonly used
parameters for
quick diagnostics
of Power Supply,
Communications,
Batteries and
Generator.
AlphaNet
TM
DOCSIS Status Monitor
General Configuration
General
Advanced Configuration Apps
History
Language
Communications: Comprehensive
communications diagnostic parameters.
Power Supply: Comprehensive Power
Supply configuration and configurable
parameters
Generator: Comprehensive Generator
configuration and diagnostic parameters
IO - Environment: Status and configuration
of Tamper polarity and external I/O devices
HMS Alarms: Status of SCTE-HMS active
alarms, alarm history and alarm threshold
settings.
(Requires AlphaApp card)
Overview: Provides AlphaApp card
version and status, plus Utility power
health information.
B
attery Management: Configure
technician ID, battery conductance
measurements, battery model and
battery manufacturing dates for
runtime and battery life calculations.
System Logs (requires AlphaApp card): Log
overview page provides snapshot of first 5 entries
from each of the system logs.
Power Supply Events (requires AlphaApp card):
Records daily power supply system events.
Power Supply Configuration (requires
AlphaApp card): Records power supply system
configuration events, many of which are set during
the initial installation.
Battery Events (requires AlphaApp card):
Records battery conductance measurements and
manufacturing dates.
Cable Modem Log: Web page representation of
the DOCSIS modem event log.
Sends the contents
of the selected
Web page to the
computer’s default
printer.
The Web page content
will be displayed in the
selected language
