1.3.4.2 Connections, continued
Multiple battery strings
A system with multiple strings must use String A as the first string, B as the second, C
as the third and D as the fourth.
3D
2D
1D
Vbatt 2
D
24V
White, Pin 6
Vbatt 1
D
12V
Gray, Pin 1
Black
Red
To XM3
3C
2C
1C
Vbatt 2C 24V Violet, Pin 7
Vbatt 1
C
12V
Blue, Pin 2
3B
2B
1B
Vbatt 2
B 24V
Green, Pin 8
Vbatt 1
B 12V
Yellow, Pin 3
Vbatt 3
A 36V
Red, Pin 9
3A
2A
1A
A/B/C/D NEG Black, Pin 5
Vbatt 2
A 24V
Orange, Pin 4
Vbatt 1
A 12V
Brown, Pin 10
POS(+)
NEG(-)
NEG(-)
NEG(-)
POS(+)
POS(+)
POS(+)
NEG(-)
NEG(-)
NEG(-)
POS(+)
POS(+)
POS(+)
NEG(-)
NEG(-)
NEG(-)
POS(+)
POS(+)
POS(+)
NEG(-)
NEG(-)
NEG(-)
POS(+)
POS(+)
1.3
Alpha XM3-HP CableUPS Layout, continued
1.3.4 Smart AlphaGuard, continued
1.0
Introduction, continued
Fig. 1-12, Multiple Battery String Wiring Diagram (w/ embedded SAG Harness depicted)
1
2
3
4
6
7
8
Back of Plug
5
9
10
