Appendix
108
017-882-B0-001 Rev. C2 (10/2013)
North American Models:
908HP
910HP
915HP
918HP
918D-HP
Fine Mode Parameters
Nominal AC Input Voltage
120VAC
120VAC
120VAC, 240VAC
120VAC, 240VAC
120VAC, 240VAC
Nominal Input Frequency
60Hz
60Hz
60Hz
60Hz
60Hz
Input Frequency Tolerance (%) ±3
±3
±3
±3
±3
Input Voltage Operating
Range Tolerance (%)
-25 / +15
-25 / +15
-25 / +15
-25 / +15
-20 / +15
Input Voltage Range (VAC)
90-138
90-138
90-138, 173-276
90-138, 173-276
96-138, 192-276
Output Voltage (VAC)
63 / 89
63 / 89
63 / 89
63 / 89
63 / 89
Output Voltage Regulation (%)
-2.5 / +1
-2.5 / +1
-2.5 / +1
-2.5 / +1
-5 / +2
Maximum Rated
Output Current
8 Amps
10 Amps
15 Amps
18 Amps
18 Amps
Maximum Output Power (VA)
720
900
1350
1620
1620
Line Mode Efficiency
Up to 94%
Standby Efficiency
Up to 91%
Output Waveform
Quasi-square wave
Short Circuit Protection
<150% of maximum current rating
Transfer Characteristics
Uninterrupted output
Battery Voltage (VDC)
36
36
36
36
36
Battery Charger
Temperature Compensation
Programmable (0 to 5mV/Cell/ºC)
Bulk Charger Current
10A
5 Stages
Refresh, Bulk, Accept, Float, Rest
Mechanical
Inverter Module
Front plug in, Hot swappable Inverter Module
Dimensions H x W x D (in/mm)
7.8 x 15 (16.7 w/handle) x 10 (10.7 w/handle) / 198.1 x 381 (424.18 w/handle) x 254 (271.8 w/handle)
Weight (lb/kg)
48.5 / 22.0
49 / 22.3
60 / 27.2
60.5 / 27.5
69.4 / 31.5
Input Power Connector
(IEC 320/C20)
NEMA 5-15P Plug
NEMA 5-15P Plug
NEMA 5-20P/
NEMA 6-15P Plug
NEMA 5-20P/
NEMA 6-15P Plug
NEMA 5-20P/
NEMA 6-15P Plug
Battery Connector
Anderson style 75A
Remote Temp Sensor
Ring lug fastens to negative terminal on center battery
Display
4 line by 20 character blue LCD with soft-key menu controls
Environment
Operating Temperature
-40 to 140°F / -40 to 60°C (derate by 3.6°F / 2ºC per 1000 feet above 3000 feet)
Humidity
0 to 95% non-condensing (relative)
Agency Compliance
Safety
CSA/UL 60950-1 (2nd), UL 1778 (4th) CSA No 107.3, C/US
EMC
FCC Part 15 Class A
Specifications
(Alpha XM3-HP CableUPS North American Models)
