Fig. 2-27, Select Language in PWR CNFG Menu
2.2
XM3-HP Start-Up Procedure, continued
2.2.8 Power Module Configuration and Installation Procedure, continued
Two output connectors will be present on the side of the front panel whether or not the optional AlphaDOC
is installed. If an AlphaDOC is not installed, the output voltage (Output 1) will be present on both
connectors as the connectors are wired in parallel by means of a split ("Y") wiring harness. If an optional
AlphaDOC is installed, the split wiring harness is replaced with individiual wiring for Output 1 and Output 2
(
Secondary loads to be connected to Output 2).
NOTE:
21. Once the unit is running on line voltage, perform a Self Test by pressing and holding the test
button for 1-2 seconds with a pen (or similar object). Wait for Self Test completion before
proceeding (see
Section 3.1.1, Self Test Operation).
22. Perform standby test by shutting off utility breaker and verifying unit goes into standby and
supports the load.
23. Re-apply AC power and verify unit goes to Line Mode.
2.0
Installation, continued
If the unit is operating from batteries, the Self Test will not initiate. Check input breaker and input line cord.
NOTE:
P
WR CNFG
OUTPUT VOLTS
OUTPUT CURR
ENTR
ESC
Power Info Menu
Default
Range
PWR CNFG
Power Config Menu
Default
Range
SELECT LANGUAGE
English
Spanish
French
Portuguese
German
The default language is set to English. Unless the XM3 is ordered preset to another language, the
language can be changed through the PWR CNFG (Power Configuration) menu. Pressing the PWR
(Power) softkey while in the OPERATION NORMAL screen opens the Power Info Menu display (the first
letter of the top line will blink indicating it is the active line; shown in orange). Pressing ENTR from this
screen opens the PWR CNFG Menu. Scroll down to the SELECT LANGUAGE menu to set to the desired
language, see Figure 2-27.
NOTE:
