59 017-882-B0-001 Rev. C2 (10/2013)
2.0
Installation
Fig. 2-39, Location of "Start" Button for Self Test
(data values shown for illustration purposes only)
2.2 XM3-HP Start-Up Procedure, continued
2.2.14 Verifying Power Supply and Battery Parameters
2.0 Installation, continued
Click the General menu to access Power Supply and individual battery voltage values. Important
parameters such as current alarm status, inverter status and tamper status can be quickly verified
on this page. Additional Power Supply parameters can be viewed and configured on the Power
Supply page located in the Advanced Configuration menu, see Figure 2-38.
Fig. 2-38, Power Supply and Battery Parameters
(data values shown for illustration purposes only)
Remote Self Tests on power supplies may be started and stopped via the DSM3 Series Web
page. This requires a Level 1 login. Refer to Section 2.2.12.1, Web Interface Security Levels
for User Name and Security Password.
To launch a remote Self Test, click on the Start Test button, see Figure 2-39.
To stop a remote Self Test before the predefined test duration, click on the Stop Test button.
2.2.15 Remote Self Tests via the Web Page
