28

017-882-B0-001 Rev. C2 (10/2013)

1.0

Introduction

1.3

Alpha XM3-HP CableUPS Layout, continued

1.3.4 Smart AlphaGuard

1.0

Introduction, continued

The Smart AlphaGuard (SAG) is an optional device that maximizes battery life.
The SAG enables the XM3-HP system to gather individual battery voltages and balance the

batteries. A description of the SAG's operation and features follows.

1.3.4.1 Theory of Operation

The Smart AlphaGuard (SAG) communicates directly with the XM3. The SAG sends

battery data, unit states and alarms to the XM3 and the XM3 sends control messages

back to the SAG.

The SAG is a battery balancer with multiple string capability and integrated intelligent

functions. It minimizes differences in individual battery voltages during the charging of

the batteries (all modes except REST) by transferring charge from a battery with a higher

voltage to the batteries with lower voltages within a string. The SAG's balancer circuit

switches between strings enabling a single SAG to service up to four strings of batteries.

To accomplish this the SAG periodically measures all the battery voltages. These

measurements are sent to the system master XM3. Voltage measurements are used

to determine the level of balance of the batteries and determine if there is one or more

batteries that need to be balanced. The level of balance will determine which string the

SAG will focus on. The SAG selects the string with the highest delta mean (Vbat-Vmean)

to balance first.

There are two SAG models available, one model for 1–2 strings, and one model for 1–4

strings.
