6 Page 6 - 2 Tank Sentinel Setup Programming Guide
Manifolds Data Menu (C
ONTINUED
...
FROM PREVIOUS PAGE
)
NAME Press M2 key.
MANIFOLD NAME N
MAN N
9 characters
Use keypad to input a name for the Manifold.
Press
ENTER to accept this data.
PRODUCT Press M3 key.
PRODUCT FOR MANIFOLD N
PRODUCT 1 Press UP/DOWN ▲ ▼ to select a product #.
:
PRODUCT 8 Press ENTER to accept this data.
( If tanks are set to manifold, then the product
section of the tank menu disappears )
DEL THRES Press M4 key.
DELIVERY THRESHOLD N
+200.000
1 to 99999.0
Use keypad to input value in volume units...
per total capacity.
Press
ENTER to accept this data.
Manifolds ALARMS Menu
Use this menu to input the Manifold Product Volume
Limits (optional). Access the ALARMS menu; go back to
the parent menu and then choose ALARMS ( press
M2 ).
ALARMS Press M2 key.
MANIFOLD ALARMS MANIFOLD
MAN 1 Press the ( M ) key to select the MAN# for alarm setup.
: (Manifold # 3 and 4 are for TS-2001/508 only)
MAN 4
COPY (Optional - used to copy alarm data) Press M1 key.
COPY MANIFOLD ALARMS X TO N Press ( M ) key to select MAN# to copy alarm data from.
MAN 1
:
MAN 4
COPY MANIFOLD ALARMS X TO N
PRESS ENTER IF YOU ARE SURE?
Press ENTER to accept this data.
LOW LIM Press M2 key.
LOW PRODUCT VOLUME LIMIT N
+0 0 to 50000.0
Use keypad to input alarm limits.
Press
ENTER to accept this data.
L LIM OG Press M3 key. (Output Group = OG)
LOW PRODUCT LIMIT OUTPUT GROUP N Press UP/DOWN ▲ ▼ to assign alarm to (OG) N
NONE Not assigned to an OG
GROUP A-FF One OG selected (A=1st OG, FF=32nd OG)
ALL GROUPS All OGs selected (see WORKSHEET #6-1)
Press ENTER to accept this data.
NOTE
