Probes Setup Page 4 - 3 4
Probes – PRESSURE PROBE DATA Menu
This grayed out section is a duplicate of the STANDARD menu - use it to assist in
following the PRESSURE PROBE DATA MENU.
PROBE DATA N PROBE # N shown typical for any probe # 1 – # 8.
COPY Press M1 key.
PROBE DATA N PROBE # N shown typical for any probe # 1 – # 8.
TYPE Press M2 key.
PROBE TYPE FOR PROBE N Press UP/DOWN ▲ ▼ keys to choose probe type.
PRESSURE Select PRESSURE (pressure probe).
when programming TS-ISCB or TSP-LLPT probes.
MODEL Press M3 key. (instead of GRADIENT for STANDARD)
PROBE MODEL FOR PROBE N Press UP/DOWN ▲ ▼ keys to choose either (TS-ISCB
or TSP-LLPT)
Press
ENTER to accept this data.
SCALE ( TS-ISCB ) Press M4 key. (instead of NO.FLOATS for STANDARD)
SCALE N
+9.03000
Use the keypad to enter the PSI as printed on the
probe.
Press
ENTER to accept this data.
OFFSET( TSP-ISCB ) Press M1 key. (instead of FLOAT TYPE for STANDARD)
PROBE OFFSET N
+0
Use the keypad to enter the OFFSET level.
Press ENTER to accept this data.
CONFIG ( TSP-LLPT ) Press M4 key. (instead of SCALE for ISCB)
CONFIGURING PROBE (ATG will check the addresses for all probes)
SCALE ( TSP-LLPT ) Press M1 key. (instead of OFFSET for ISCB)
SCALE N
+9.03000
Use the keypad to enter the PSI as printed on the
probe.
Press
ENTER to accept this data.
ENA TEMP ( TSP-LLPT ) Press M2 key.
TEMPERATURE ENABLE N
NO
Press UP/DOWN ▲ ▼ keys to choose either (NO or YES)
YES Press ENTER to accept this data.
OFFSET( TSP-LLPT ) Press M3 key.
PROBE OFFSET N
+0
Use the keypad to enter the OFFSET level.
Press ENTER to accept this data.
NOTE
☞
