Communication Ports Setup Page 21 - 5 21
COMM PORT 2 Menu (Continued... )
DELIVERY (Report Deliveries to:)
DELIVERY DIAL STRING
blank up to 4 numbers
ALARMS (Report Alarms to:)
ALARM DIAL STRING
blank up to 4 numbers
LEAKS (Report Tank Leaks to:)
LEAK DIAL STRING
blank up to 4 numbers
LINES (Report Line Leaks to:)
LINE DIAL STRING
blank up to 4 numbers
— Press the DOWN ▼ key to show more menu items —
SCALD (Report SCALD Tank Leaks to:)
SCALD DIAL STRING
blank up to 4 numbers
SECURITY (Input a security code to limit access to the Tank Sentinel
SECURITY CODE console data base ...highly recommended)
blank up to 6 characters
DATA MODE Menu
Use the DATA MODE – internal Tank Sentinel
modem – for remote connection to IBM PCs.
Go back / display these menus (at left) and
press
M3 and then M1 to access Data
Mode.
DATA MODE
MODE Press M1 key.
COMMUNICATIONS MODE
NATIVE Use UP/DOWN ▲ ▼ keys to show choices.
VEEDER ROOT Press ENTER to accept this data.
— CONTINUED ON THE NEXT PAGE —
NOTE
☞ Cycle console power on and off
after programming is done, or after
any COM PORTS setting is
changed. Also, when the data / fax
modem is present, press CHECK &
M3 DIALTONE to see if a dial tone
is detected.
___ Dial Strings
reference sets of
remote access
and phone
numbers
(NUMBERS 1 thru
4) that are
programmed in the
AUTODIAL menu.
For example:
Input a 1 2 to
automatically call
and send data to
phone numbers 1
and 2.
FAX/MODEM *
D ATA M D F A X M O D E
*
M1 M2 M3 M4
COMM PORTS
COMM 1
COMM 2 FAX/MODEM
*
M1 M2 M3 M4
