Dipsw menu 28, Dipsw 28, Dipsw menu – Franklin Fueling Systems Tank Sentinel (TS-1001, 2001, 504, & 508) Setup Programming Guide User Manual
Page 163
28
Page
28 - 4
Tank Sentinel Setup Programming Guide
DIPSW Menu
DIPSW
Here is the SELECT DIAGNOSTIC OPTION menu
displaying RESET, DIPSW and CALIBRT menu
names.
Press the
M2
key under the selection DIPSW.
Here is the default DIPSWITCH OVERIDE
display ....
Press the
M4
key to backspace and erase the
‘1B8C’ default setting.
Use the keypad to enter a particular Dip Switch
setting.
Remember:
• Use the
SHIFT
key to change the keypad from
A...M to N...Z and to (numeric)
1-9, 0, ., +/–, and SPACE (a blank space)
Press the
ENTER
key to accept data entry.
The display returns to the SELECT DIAGNOSTIC OPTION menu.
Repeat the user interface steps for each pump.
— Proceed to the next DIAG Menu section - CALIBRT Menu —
SELECT DIAGNOSTIC OPTION
RESET
D I P S W
CALIBRT
M1
M2
M3
M4
ENTER DIPSWITCH OVERIDE VALUE:
NUMERIC
1B8C
BACKSPACE
CAUTION!
Changing Dipswitch settings should
be used for diagnostic purposes only.
Consult controller manuals for switch
settings and their meanings.
