Diagnostic Menu
Page
28 - 3
28
RESET Menu
RESET
Here is the SELECT DIAGNOSTIC OPTION menu
displaying RESET, DIPSW and CALIBRT menu
names.
Press the
M1
key under the word RESET.
The RESET PUMP 1 display asks if the user is
sure before resetting a pump controller; giving the
user a chance to press
CANCEL
to abort the reset
operation.
Press the
ENTER
key to reset the pump control-
ler.
(Press the
CANCEL
key to abort the reset
operation.)
After entering a reset, the display will flash the word DONE ... for a few
seconds and then it will automatically return to the SELECT DIAGNOSTIC
OPTION menu, displaying RESET, DIPSW and CALIBRT.
— Proceed to the next DIAG Menu section - DIPSW Menu —
SELECT DIAGNOSTIC OPTION
R E S E T
DIPSW
CALIBRT
M1
M2
M3
M4
R E S E T P U M P 1
ARE YOU SURE?
DANGER!
The potential for electric shock exists!
Verify the site is safe! — before
proceeding with a
Reset
operation.
DANGER!
The potential for electric shock exists!
Verify the site is safe! — before
proceeding with a
Reset
operation.
