PREFACE Page P - iii P
Scope of This Manual
This manual shows the setup-programming of Tank Sentinel system. Each Chapter is
dedicated to a specific parent menu (see Parent Menus below).
Menu Conventions
The menu structure in this manual is shown in an indented format:
PARENT MENUs are above and to the left of sub-menus and
SUB-MENUs are below and to the right of parent menus.
Default VALUES, SETPOINTS, & LIMITS are shown first and in ITALIC text.
Parent Menus
UPPER ROW – DISPLAY TEXT
LOWER ROW – DISPLAY TEXT
MENU keys M1 thru M4
Numbers within boxes are
Chapter #s. Some parent menus, or
sub-menus will not appear unless:
* a related setup menu / feature is selected
** the accessory (hardware) is installed and the
system is powered up
*** the appropriate options have been purchased
Key Action
MENU keys – use (press) to:
• choose / display other menus or sub-menus
or exit SETUP mode
• move the cursor left or right through a text
string ( M1 = left, M2 = right)
• backspace over / delete a character in a text
string ( M4 backspaces from the right)
KEY PAD keys – use (press):
• ï
CANCEL to cancel an input or to exit out
of a menu
• ▲ UP or DOWN ▼ to display more menus
when (MORE) is shown, or other selections
from a sub-menu when (UP/DN) is shown
• Use the ENTER key to accept the displayed
choice or value for storage into setup memory
S E L E C T M E N U O P T I O N (MORE)
SETUP UPGRADE LANGUAGE DATALOG
M1 M2 M3 M4 NOTES
☞
SETUP MENU (MORE)
EXIT SYSTEM TANKS LINES
M1 M2 M3 M4
SETUP MENU (MORE)
PROBES PRODUCTS RECONCILE DIM
M1 M2 M3 M4
SETUP MENU (MORE)
REPORTS LK TESTS SCLD TEST LN TESTS
M1 M2 M3 M4
SETUP MENU (MORE)
CLK/CAL ANNUNC RELAYS SENSORS
M1 M2 M3 M4
SETUP MENU (MORE)
AUX INPUT CPM C O M P O R T S CVS
M1 M2 M3 M4
1 2* 3***
20
5* 6* 7 4*
9*** 10*** 11 8***
13 15* 12
16
14**
18 17** 19
21 22
