Upgrade Page 24 - 3 24
This message will be displayed if an
incorrect password was entered.
See the WARNING on page 1 of this Chapter
...verify that the upgrade password is
entered correctly before you press the
ENTER key !
This message is displayed when the upgrade
password was entered correctly, and after
each upgrade string is entered.
SYSTEM UPGRADE FUNCTION
STRING 1 ............................................................ 2 ) Press M1 to input upgrade string # 1
( see example below-left )
STRING 2 ............................................................ 3 ) Press M2 to input upgrade string # 2
STRING 3 ................................................................ 4 ) Press M3 to input upgrade string # 3
5 ) Press the M1 , M2 & M3 keys again
and verify that all of the upgrade strings are
correct before you press
M4 under RUN.
Correct any upgrade string as necessary.
RUN ....................................................................... 6 ) Press M4 under RUN choice to “run”
the upgrade after all of the strings have been
verified correct.
When the upgrade is successful , the Tank
Sentinel console will display this fact. It will
then reboot and enter the setup mode
automatically...
7 ) Access the new / expanded menu(s) and
program the console to operate with these new
upgrade features.
If an upgrade is not successful, this
message is displayed (setup data is illegal).
A Transient Watchdog Time-out Warning will
appear. Press the
ACK key to acknowledge the
warning and it will clear.
SETUP DATA IS ILLEGAL
M1 M2 M3 M4
NOTE
☞
SYSTEM UPGRADE FUNCTION
STRING 1
STRING 2 STRING 3 RUN
M1 M2 M3 M4
PASSWORD IS ILLEGAL
M1 M2 M3 M4
example UPGRADE string # 1
UPGRADE STRING 1 NUMERIC
51D1 51D2 51D3 51D4 BACKSPACE
NOTE
☞
