2 Page 2 - 6 Tank Sentinel Setup Programming Guide
Tanks – SPECIAL TANK N Menu (C
ONTINUED
)
SPECIAL TANK N N refers to / represents a tank number
COPY Press the M1 key.
COPY FROM SPECIAL TANK X TO N Select a tank to copy data from (use M key).
SPECIAL 1
COPY SPECIAL TANK N TO N
PRESS ENTER IF YOU ARE SURE?
Press ENTER to accept this data.
Use UP / DOWN ▲▼ keys to display tanks 5-8.
DIAMETER Press the M2 key.
TANK DIAMETER N
+96.00 0.0 to 999,999
Use the M4 key to use BACKSPACE.
Use the Keypad to input the special tank diameter.
Press
ENTER to accept this data.
LENGTH Press the M3 key.
TANK LENGTH N
+324.000 0.0 to 999,999
Use the M4 key to use BACKSPACE.
Use the Keypad to input the special tank diameter.
Press
ENTER to accept this data. (Correction points
can be added between inaccurate level positions.)
(HEIGHT will replace LENGTH when VERTICAL is selected as the TANK DATA SHAPE)
HEIGHT Press the M3 key.
TANK HEIGHT N
+324.000 0.0 to 1999.0
Use the M4 key to use BACKSPACE.
Use the Keypad to input the special tank diameter.
Press
ENTER to accept this data.
CORR TABL Press the M4 key.
CORRECTION TABLE N (Position (POS #) ...see NOTES in this section)
ADD Press the M1 key. POS 1 is the lowest value tank.
Two values (LEVEL and VOLUME) are required.
LEVEL +0 Use the Keypad to input level of strapping point.
Press ENTER to accept this data.
VOLUME +0 Use the Keypad to input volume at that level point.
Press ENTER to accept this data.
NOTE
☞
