29 Page 29 - 4 Tank Sentinel Setup Programming Guide
NOTE: Diagnostic text in the left column, is shown bolded { become alarms if active for 48 hours }
#
Printed / Faxed / Displayed
Alarm / Warning Text:
Alarm Type:
System WARNING / Error Descriptions and
ALARM Descriptions
(actions to take)
35
ALPHA ERROR / ALPHA ERR
/ ALPHA V
SYSTEM
Error in API temperature compensation calculating
ALPHA (check any Special Products -- reprogram
temperature compensation type & API ALPHA
value).
36 API ERROR / API VOL SYSTEM
Error in API temperature compensation routine
(check any Special Products -- reprogram
temperature compensation type).
37 CPM FAILURE SYSTEM
No Power / Power is below 5 VDC - Check Power
Supply / Increase Voltage (if possible)
38 CPU CRASH SYSTEM
WARNING - Central Processing Unit / hardware
failure / power quality problem
39 DATA ERROR / DIM SYSTEM
Transient communication error between the Tank
Sentinel and TS-DIM unit. This alarm/error will
clear itself automatically.
40 DATA NOT AVAILABLE / DIM SYSTEM
Transient alarm/error caused when TS-DIM unit is
'busy' performing another task and cannot make
the requested data available until it is not 'busy'.
This alarm/error will clear itself automatically.
41 DIM COMM FAILURE SYSTEM
Tank Sentinel has lost communications with the
TS-DIM unit. Verify power to the DIM / Verify
proper connection between DIM and console.
42 F14 OPEN / F14 FUS SYSTEM
WARNING - FUSE F14 is blown... no 5 VDC
Sensor Supply Power. Leak detection sensors are
not working and cannot work without power
(call
service provider immediately to replace F14)
43
FAX HARDWARE FAILURE /
FAX HW FAIL / FAX FAL
SYSTEM
WARNING - Fax Hardware Failure... alarms &
compliance faxes cannot be sent
(call service
provider ASAP)
44 FAX SND FAIL / FAX SND SYSTEM
WARNING - Fax Send Failure... (check Dial tone,
cable, call service provider... are the fax phone
numbers correct ?)
45
FLOAT HEIGHT / FLOAT HT /
FLT HT
SYSTEM
WARNING - Float Height - calculation Error (setup
program error... call service provider)
46
FLOAT MISSING / FLT
MISSNG / FLT MIS
SYSTEM
WARNING - diagnostic warning Float Missing (call
service provider)
47 LEAK SYSTEM
WARNING - a Leak detected @ Tank N during the
after hours Sentinel mode
(shut down dispensing,
see procedures at your site... 1. Shut off pump /
dispenser power 2. Retest / start a Standard 0.2
gph tank test for Tank N, 2 hours after the last
dispense 3. Retest & See Chapters 3 & 4
