21 Page 21 - 2 Tank Sentinel Setup Programming Guide
COMM PORT 1 Menu (Continued... )
BAUD Press M2 key.
BAUD RATE
9600 BAUD Use UP/DOWN ▲ ▼ keys to show choices.
300 BAUD Press ENTER to accept this data.
:
19,200 BAUD
DATA BITS Press M3 key.
DATA BITS
8 BITS Use UP/DOWN ▲ ▼ keys to show choices.
7 BITS Press ENTER to accept this data.
STOP BITS Press M4 key.
STOP BITS
1 STOP BIT Use UP/DOWN ▲ ▲ ▲ ▲ ▲ ▼ keys to show choices.
2 STOP BITS Press ENTER to accept this data.
— Press DOWN ▼ key to show more menu items —
PARITY Press M1 key.
PARITY
NO PARITY Use UP/DOWN ▲ ▼ keys to show choices.
ODD PARITY Press ENTER to accept this data.
EVEN PARITY
ECHO TEST Press M2 key.
ECHO TEST ACTIVE…
HIT ANY KEY TO QUIT
SECURITY Press M3 key.
SECURITY CODE
(blank) 6 characters
Use keypad to input a maximum of six characters.
Press
ENTER to accept this data.
(used to limit access to the Tank Sentinel console (highly recommended)
—
CONTINUED ON THE NEXT PAGE
—
