A Page A - 2 Tank Sentinel Setup Programming Guide
TYPE CAPACITY DIMENSIONS S / DW
# MANUFACTURER MODEL (GALLONS) D x L (INCHES) WALL
23 O/C TANKS DWT-2(10) 30,000 124 X 656 D
24 XERXES — 2,000 96 X 108 S
25 XERXES — 2,000 76 X 166 D
26 XERXES — 2,000 75 X 144 S
27 XERXES — 3,000 96 X 147 S
28 XERXES — 4,000 75 X 263 S
29 XERXES — 4,000 96 X 180 S
30 XERXES — 4,000 76 X 252 D
31 XERXES — 6,000 75 X 353 S
32 XERXES — 6,000 96 X 246 S
— 6,000 97 X 251 D
33 XERXES — 8,000 96 X 312 S
— 8,000 97 X 317 D
34 XERXES — 10,000 96 X 378 S
— 10,000 97 X 383 D
35 XERXES — 10,000 124 X 257 S
— 10,000 125 X 262 D
36 XERXES — 12,000 96 X 444 S
— 12,000 97 X 449 D
37 XERXES — 12,000 124 X 288 S
— 12,000 125 X 293 D
38 XERXES — 15,000 124 X 353 S
— 15,000 125 X 359 D
39 XERXES — 20,000 124 X 452 S
— 20,000 125 X 458 D
40 CORESPAN — 4,000 99 X 162 D
41 CORESPAN — 5,000 99 X 192 D
42 CORESPAN — 6,000 99 X 216 D
43 CORESPAN — 8,000 99 X 282 D
44 CORESPAN — 10,000 99 X 342 D
45 CORESPAN — 12,000 99 X 402 D
46 CORESPAN — 15,000 99 X 576 D
47 — — 275 44 Vertical S
48 — — 550 44 Vertical (Dual 275 gal.) S
49 — — 275 44 Horizontal S
— ❖ —
