D Page D - 2 Tank Sentinel Setup Programming Guide
T2PM/8SDCL = TS-2001 with Printer, Modem / 8 tank, SCALD, Data (modem),
Canadian, TS-LLD (RS-485 Line Leak Detector Interface)
(T) = standard 120 V AC
V2P1/8GR = Export single pole 240 V AC, Neutral & Ground power
configuration, TS-2001 with Printer, 1 Internal Expansion
Module (IEM) / 8 tank, Generator, Reconciliation
T508P/8 = TS-508 with Printer/ 8 tank
T508PM/8FCR = TS-508 with Printer, Modem / 8 tanks, Fax and Data
(modem), Canadian, Reconciliation
Part Number Codes & Meaning
The following options are available:
See the Chapter in this manual about Upgrading the Tank Sentinel system with
optional add-on features.
— ❖ —
NOTE
☞
Field 1
Options
Field
Separator
Field 2
Options
T or V
1
2
504
508
P
M
1 or 2
/
0
2 or 4
8
S or G
D or F
C
L
R
L = Line Leak Detector Interface (RS-485 in console)
8 = 8 tank A.T.G. + L.D.S.
S = SCALD or G = Generator
D = Data modem or F = Fax / Data modem
C = Canadian / Export Tank Sentinel
1 = 1 TS-IEM (TS-2001 only) or 2 = 2 TS-IEMs (TS-2001 only)
...separates part number fields...
0 = zero tank L.D.S. (Leak Detection System)
2 = 2 tank or 4 = 4 tank A.T.G. + L.D.S.
R = Reconciliation, used with TS-DIM
T = Standard voltage 120 VAC or V = Export voltage 240 VAC
Part Number Codes
Part Number Code Descriptions
1 = TS-1001(All Options except TS-IEM)
P = Printer
2 = TS-2001(All Options)
504 = TS-504 (No SCALD, LLD, Generator - No Tank Testing)
508 = TS-508 (No SCALD, LLD, Generator - No Tank Testing)
M = Modem
