Press the DOWN ▼ key until CVS is displayed - alignment with
menu keys depends on the programming of other features.
SETUP MENU (MORE)
EXIT SYSTEM TANKS PROBES
SELECT MENU OPTION (MORE)
S E T U P UPGRADE LANGUAGE DATALOG
M1 M2 M3 M4
CVS Menu
Before Programming:
• Have the power switched ON at the Tank Sen-
tinel Console and at the power panel.
• Reference the INCON CVS Manual (INCON PN:
000-1095) for details about this feature.
• From the SETUP>SYSTEM menu – program
the units of measure, correct number of tanks,
and correct number of leak detection sensors.
Also, program the: sentinel mode limits, deliv-
ery delay, report delivery and alarm, and the
max size of the historical records that will used
in reports.
Character input / editing:
• Push UP/DOWN keys ▲ ▼ to show more
menus or menu selections.
• Use menu keys ( M1 to M4 ) to access
menus.
• Press ENTER to accept a selection or input a
value into the setup configuration memory.
• Press CANCEL to cancel data entry
• Press M1 to move the cursor left
ï
• Use M2 to move the cursor right
ð
• Press M4 to backspace (delete) one charac-
ter to the left
ï
CVS TANKS
TANK 1 Press the M1 key.
— CONTINUED ON NEXT PAGE —
22 Compliance Via Sensors (CVS)
SETUP PROGRAMMING
H U
MENU
×
Press this key and follow the
7 highlighted sequence below
COMPLIANCE VIA SENSORS
T A N K S LINES
M1 M2 M3 M4
SETUP MENU (MORE)
CPM C O M P O R T S CVS
M1 M2 M3 M4
