Input
[HDMI/VGA/None]
Input
[Resolution]
Input
[Format]
Device [Firmware Version]
[Device Serial Number]
Device [Firmware Version]
[Name]
Device LAN2
[IP Address]
Device LAN2
[Subnet Mask]
Connection [n] [Transport]
[Connection count]
Connection [Transport]
[Bit rate]
Connection [Transport]
[Status]
Controller
[IP Address]
Controller
[Status]
Input
Device
Controller
Connection
Figure 74. VNE 250 Encoder Default Menu Screens
Top Level Menu
These screens provide access to configure the encoder device.
NOTE: Some settings take a few seconds to action once a change is made.
To access the top level menu:
1. Press the Menu button to access Encode Config, the first item in the top level menu
(see figure 74 on the following page).
2. Continue pressing the Menu button to scroll through all the available top level options.
3. When the desired option appears in the LCD window, press the Next button to select
the submenu options.
NOTE: If you cycle through all the top‑level options, continuing to press the Menu
button will take you back to the first option (Encode Config).
VNM 250 • Front Panel Menu Configuration 92
