Genlock Sub-menu
The Genlock sub‑menu allows you to enable or disable genlock and to determine whether
the display will be a master or slave.
Genlock
MENU NEXT
Genlock
[Enable]
NEXT
Select: Enable
Disable
Disable Enable
NEXT
Frame lock Ref
[None]
Select:
None
[list of available devices]
NEXT
Figure 91. VND 250 Decoder Genlock Sub-menu
1. In the main Genlock screen, press Next to open the Genlock mode selection screen.
2. Use the left rotary encoder to toggle between Enable and Disable. Enable ties the
display to the Genlock signal. Disable displays the signal without tying it to the Genlock
signal.
3. Use the right rotary encoder to select a decoder to be the master frame lock device.
4. Press Next to return to the main Genlock screen.
5. Press Menu to open the Reset sub‑menu screen.
Reset Sub-menu
The Reset sub‑menu allows you to reset many parameters to the factory defaults. It also
allows you to run the Sanitize process.
Reset
MENU NEXT
Reset [Factory IP]
[Activate]
NEXT
NEXT
Are you sure?
[Yes]
System Reset
in progress
Figure 92. VND 250 Decoder Reset Sub-menu
1. In the main Reset screen, press Next to open the Reset Options screen.
VNM 250 • Front Panel Menu Configuration 109
