Low Level Device
Configuration
The RS‑232 control port is used to configure the network settings for the VNE 250 and the
VND 250. Follow these instructions:
1.
Use an RS‑232 cable to connect a control PC to the
of the
VNM 250 device (see page 19).
2.
On the PC or laptop, open a terminal emulation program, such as Extron DataViewer,
with the following settings:
z
Baud rate: 115200
z
Data bits: 8
z
Parity: None
z
Stop bits: 1
z
Flow control: None
NOTE: DataViewer can be downloaded, free of charge, from the Extron website
(
).
3.
Enter the
User name
and
Password
.
NOTES:
•
When DataViewer first opens, it may be necessary to press
User
name
prompt to appear.
•
By default, the User name is
config
and the Password is also
config
.
The low level configuration menu opens (figure 11 shows default values):
Control Network port
====================
Streaming Network port
======================
0. Speed/Duplex: auto_10_100_1000
1. IP Prov mode: static [dhcp]
2. address: 192.168.253.254
3. netmask: 255.255.255.0
6. mtu: 1500
7. VLAN ID: 0
8. controller ip: 192.168.254.254
9. Exit
10. Speed/Duplex: auto_10_100_1000
11. IP Prov mode: static [dhcp]
12. address: 192.168.254.254
13. netmask: 255.255.255.0
14. gateway: 192.168.254.1
16. mtu: 1500
17. VLAN ID: 0
18. Controller port: 5432
19. webserver port: 80
Please select an option:
Figure 11.
Low Level Configuration Menu Page 1
NOTE: These values are held in local memory on the unit itself.
VNM 250 • Low Level Device Configuration
