Top Level Menu
To access the top level menu:
1. Press the Menu button to access the first item in the top level menu (Decode Config).
2. Continue pressing the Menu button to scroll through all the available top level options
3. When the desired option appears in the LCD window, press the Next button to select
the submenu options.
NOTE: If you cycle through all the top‑level options, continuing to press the Menu
button will take you back to the first option (Decode Config).
Decode
Config MENU NEXT
MENU
NEXT
OSD
MENU
MENU
MENU
MENU
MENU
Network
NEXT
Reset
Test
Pattern NEXT
Video wall
NEXT
Output
NEXT
See
See
See
See
See
See
NEXT
See
MENU
Genlock
NEXT
See
MENU
Exit Menu
Press Next NEXT
Exit menu and return to default screens
Figure 84. VND 250 Decoder — Top Level LCD Menu
Decode Config sub-menu on page 102.
OSD sub-menu on page 103.
Reset sub-menu on page 109.
Genlock sub-menu on page 109.
Output sub-menu on page 106.
Video wall sub-menu on page 107.
Test Pattern sub-menu on page 108.
Network sub-menu on page 103.
VNM 250 • Front Panel Menu Configuration 101
