z
8
— this option sets the IP address of the system controller. The controller IP
address must be set to the IP Address of the streaming port on the unit designated
as controller. This is the network port over which system control data is sent. The
default value is
192.168.254.254
.
z
18
— this option sets the number of the port that is used for communications with
the system controller. The default value is
5432
but it may be changed, if required.
All units in the system must have the same port number assigned.
z
19
— this option sets the number of the port that communicates with the web
server. The default value is 80 but it may be changed, if required. The web browser
in use must use the same port number.
NOTE: Option
19
is only available when the device is configured as the system
controller.
z
9
— this option allows you to exit the network port configuration page and opens
the Controller and DHCP Configuration page. Any changes that have been made
are activated only after exiting the Controller and DHCP Configuration page and
rebooting.
5.
Select
9
followed by
The DHCP configuration settings page opens:
6. DHCPD/SLAAC server enable: dhcp
7. DHCP IP range: 192.168.254.200 192.168.254.254
9. Exit
Please select an option:
Figure 12.
Low Level Configuration Menu Page
NOTE: The settings in this menu apply only when the device is configured as the
system controller.
6.
At the
Please
select
an
option:
prompt, type the number of the parameter you wish
to change followed by
z
6
— this option enables or disables the DHCP/SLAAC server. To enable the server,
enter
dhcp
followed by
none
followed by
NOTE:
dhcp
and
none
are all lower case letters.
z
7
— this option sets the DHCP IP range and is only available when DHCP is
enabled (option
6
). Enter the DHCP pool address range in the following format:
xxx.xxx.xxx.xxx
where the lower IP address value and the upper IP address value are separated by
a single space.
z
9
— this option saves all changes, closes the Controller and DHCP config page,
and automatically reboots the device in the config login.
7.
Select
9
followed by
The Controller and DHCP configuration settings page closes and the device
automatically reboots to the config login screen. The changes that were made in steps
4‑6 are implemented.
