MS9500GL HD FrEND Plus
Appendix D: Specifications
Better than ATSC quality using data rates up to 35Mbps
1920 x 1080, 1280 x 1024, 1024 x 768, 720 x 480
16:9, 4:3, 5:4, Aspect Ratio support
Flexible Format Converter
High quality up / down converter of source video to selected display format.
Video Output Formats
SMPTE274M / SMPTE296M
Aspect Ratio 16:9, 4:3, 5:4
1920 x 1080i
1280 x 720p
1024 x 768p
720 x 576p
720 x 480p
Video Outputs Electrical
Analogue Output Color Space Support
SMPTE 170M
SMPTE 240M
ITU-R-BT-709
ITU-R-BT-470-2-SystemM
Audio
Stereo Audio Output via Dual RCA Phono Sockets.
Audio Output Level 3Vp-p max
Range +30db –97db
Audio Processing
Dolby Digital AC3
Sampling Rates 32KHz, 44.1KHz, 48KHz
Audio Bit Rate 192Kbps/384Kbps/448Kbps
