MS9500GL HD FrEND Plus Chapter 1: Introduction/Quick Reference Guide
NOTE: If no filenames appear in the ‘Playlist Display’ area it may be due to a Network Conflict. Check and /or
correct any network conflict as follows:
1. Correct the Network Conflict: Refer to the Communications section in Chapter 2 for information on
setting the IP address using the LCD interface.
2. Restart the MS9500GL, after which the GUI will display the names of the clips in the current playlist
Alternatively you may:
1. Click File | Open and navigate to C:\Program Files\MediaSonic\HDPlayer.
2. Select a .vsf file from the list (there will be at least one).
3. Click Open. The test file name will appear in the Playlist Display. You can play the file but the Network
Conflict must be resolved before the unit can be integrated into a control system.
To play a Test File from the HD Player application:
1. Double click the clip in the Playlist, this will Cue the start of the clip
2. Click (Play) button on the Transport to begin playing the clip. A video image will appear on your
display device.
3. Click (Pause/Stop) button to quit or click , the MS9500GL will re-cue the clip (this may take
a few seconds), next click to restart the clip.
IR Remote (Hand-Held)
Use the Hand-Held IR Remote to trigger certain functions on the MS9500:
• PLAY - Cues and Plays the FIRST clip in the HD Player Application Playlist
• STOP – Stops the clip and displays a blank screen.
NOTE: The IR remote will not function if no clips are present in the HD Player playlist.
NOTE: If the HD Player Application has been closed for some reason you may double-click the icon
on the MS9500GL desktop to restart the application.
17 Rev. 1.26
