MS9500GL HD FrEND Plus Chapter 3: Player Configuration – HD Application
Chapter 3: Player Configuration - HD Application
The MS9500GL HD Player application provides a number of configuration options that can be used to control the
Player’s functionality. These options cover the output signal format, startup behavior and other features that are
set once and not changed as part of the show control system.
The HD Player application duplicates many of the LCD panel control features as well as providing access to
several additional user features. Use the HD Player Control Application to:
• Set video output format (also accessible with the LCD)
• Adjust video output resolution (also accessible with the LCD)
• Set Audio output format
• Assemble and organize Playlists. Note: Playlists assembled in the GUI can only be saved as part of a
.vsf file and are accessed manually from the GUI. Playlists assembled from the LCD interface are
displayed in the GUI during playback (as well as being available for remote control).
• Remote control your system with commands from other devices
These and other features of the Electrosonic HD Player application will be described in detail below.
The Channel Properties dialog
Use this interface to access the GUI configuration features.
• Right-Click the Playlist area and select Channel Properties from the drop down menu.
The Channel Properties dialog box appears (shown below), containing a number of different settings necessary for
optimum performance of your HD Player.
Note: You must select Save from the File/Save menu to keep any changes made in the Channel Properties dialog
25 Rev. 1.26
