MS9500GL HD FrEND Plus Chapter 11: Remote Control Configuration
The Remote Control Wizard - Method Type dialog
The first screen in the wizard requires two pieces of information, the method name and the physical connection
type. Every method must have a unique name, which is used to identify the method in the Log window. There are
currently two physical connection types, Serial (RS232) and TCP/IP.
Click here to choose a type
Click on the list to select either Serial or TCP/IP
Click Next to advance to either the Serial Control Parameters page or the TCP/IP Configuration page.
Information for the Serial Control Parameters is given next, followed by information for TCP/IP Configuration.
The Remote Control Wizard - Serial Control Parameters (RS232) page
This page of the wizard will appear if Serial (RS232) was selected from the “Method Type” page described above.
The page is used to select the parameters for the serial port, from the following allowable settings.
Serial port: Choose from the COMs available
BaudRate: 1200, 2400, 4800, 9600, 19200, 57600, 115200.
Parity: Odd, Even or None.
Stop Bits: 1 or 2 stop bits.
