MS9500GL HD FrEND Plus Chapter 1: Introduction/Quick Reference Guide
15 Rev. 1.26
LCD: “Quick Start”
Assuming correct connection of the MS9500GL into a display system, perform system steps 1-3 below to turn on
the player:
1. Turn ‘on’ the main POWER OFF/ON switch at the rear of the player (the power LED on the front panel
will glow). NOTE: Should the power Led not illuminate, verify that the power supply is securely
connected then toggle the power switch between OFF/ON.
2. The Hard Drive Led will flash during initialization (this could take about 30seconds).
3. During initialization the LCD display will show the message ‘HD FrEND Plus MS9500GL’ changing to
default page with MENU in the top left corner at completion.
Additionally, the HD Player application will appear on the computer monitor.
To play a Test File from the LCD interface:
The user may wish to view the Test File(s) present on the MS9500GL:
1. Using the , from the MENU page navigate to MENU | Content | Local | Files | xxx.mpg | Play.
2. Press the to play the file. The display will momentarily change to ‘Preparing to play’ then returns
to the list of available clips (files).
3. The file begins playing.
