86 Installation & Operation Manual, GE Series DPB Busway
March 25, 2013, Rev 0 GE Confidential
Series DPB Busway Installation & Operation Manual
APPENDIX F: SPECIFICATIONS
GENERAL
Operating Temp. Range: -10° to 60° C at 95% Relative Humidity (Non-Condensing)
Storage Temp. Range: -40° C to 70° C
Input Power (Power Supply Input): Maximum Ratings @ 50/60 Hz
Input VAC Input Amps
480 220 mA
380 270 mA
240 430 mA
208 500 mA
120 860 mA
Output Power (Power Supply Output): Maximum Output Ratings - 3A @ 24 VDC
INPUT PM BOARD SPECIFICATIONS
AC Current Channels: 2 X 3 Phase
(A,B,C,N,G) ; CT determines current
AC Voltage Channels: 2 X 3 Phase
(A,B,C,) 480 VAC max input
Frequency: 50 / 60 Hz
Outputs: 2 X Form C Contacts (5A)
INTELLIBUS BOARD SPECIFATIONS
Current Channels: 1 X 3 Phase (A,B,C)
Frequency: 50 / 60 Hz
Temperature Inputs: 4 remote temperature probes
Current Accuracy: 1%
Voltage Measurement Range: 0 – 480 VAC
Voltage Accuracy: 1%
