Series DPB Busway Installation & Operation Manual
CHANGE MODBUS RTU FROM RS422 TO VIA ETHERNET
1.) On the SETUP screen press the “Modbus Setup” button.
2.) Enter User ID and Password, and press the “Modbus Setup” button again.
3.) From the CHANGE ACTIVE CONTROLLER screen, Select “ModbusMaster”
so it is highlighted, and press “Settings” buton.
4.) The settings should look like the following:
M
odbus
M
ode
V
ia
Rs422 V
ia
e
theRnet
Settings
- Communication Mode Serial Serial
- Default Station 1 1
- Modbus Protocol RTU RTU
- 32bit Work Mapping Motorola Motorola
- Addressing Decimal Decimal
- Start Address 1-based 1-based
- Max Block Size (words) 16 16
- Force Function Code 0x10 Disabled Disabled
- String Swap Disabled Disabled
- Silent Time (ms) 1 1
- Clock Register 0 0
- Serial
- Port
Com2 Com2
- Baud 9600 9600
- Parity Even Even
- Data bits 8 8
- Stop bits 1 1
Advanced
- Enable Unicode False False
- Byte Order Intel Intel
- Timeout 400 400
- Retries 3 3
- Offline station retry time 10 10
- Hide Comm. Error False False
- Command Line Option
