Series DPB Busway Installation & Operation Manual
BUSWAY SYSTEM MOUNTING
SPECIFIED AND SAFE OPERATION OF THE SERIES DPB BUSWAY IS DEPENDENT ON ITS
PROPER INSTALLATION. MISALIGNMENT OF THE BUSWAY COMPONENTS, (END FEEDS,
BUS RAILS, AND SPLICES) WILL COMPROMISE ITS PERFORMANCE.
1) End Feed enclosures must be securely mounted so that they are completely level (side-to-side and front-to-back).
2) Bus Rails must be securely installed so that they are level and completely aligned to the End Feed enclosures and with
adjoining Bus Rail sections.
3) When each Busway run is properly supported / mounted, leveled , and aligned, all Splices must be verified to be
"un-cammed" (not actuated with Cam Actuator Tool).
4) The Splice units must be able to move freely and fully into both sections of adjoining sections of bus before the Splices can
be "cammed" (actuated).
5) Once the free movement of the Splice units is verified, the Splice can be actuated. The installation of Dowel Pins completes
the correct installation of the Splices.
