Series DPB Busway Installation & Operation Manual
78� R Percent load phase 2C
These registers show crest factor per phase� Values are peak current/rms current with three decimal places
(1412 = 1�412)�
79�
R Crest Factor phase 1A
80� R Crest Factor phase 1B
81� R Crest Factor phase 1C
82� R Crest Factor phase 2A
83� R Crest Factor phase 2B
84� R Crest Factor phase 2C
The following Warning Register sets a bit for every channel, which reads a current above the Warning
Threshold for at least the Warning Time-Delay� All warnings are latching and must be reset by the controller�
To reset any alarm, read the register and the write the register with the desired alarm bit cleared�
85�
R/W NV Warning Register (Latching)
bit 0: Phase 1A
bit 1: Phase 1B
bit 2: Phase 1C
bit 3: Phase 2A
bit 4: Phase 2B
bit 5: Phase 2C
bits 6 – 15: Not Used Always read as 0
The following Alarm Register sets a bit for every channel, which reads a current above the Alarm Threshold for
at least the Alarm Time-Delay� All alarms are latching and must be reset by the controller� To reset any alarm,
read the register and then write the register with the desired alarm bit cleared�
86�
R/W NV Alarm Register (Latching)
bit 0: Phase 1A
bit 1: Phase 1B
bit 2: Phase 1C
bit 3: Phase 2A
bit 4: Phase 2B
bit 5: Phase 2C
bits 6 – 15: Not Used Always read as 0
The following Warning Threshold register sets the thresholds for the Warning alarms� A Warning alarm is
given in percent of the Full load registers (75 = 75%)� A Warning alarm will occur if the measured current is
above the Warning Threshold for at least the Warning Time Delay� Default for the Warning thresholds is 70%�
The Values that are written to the Warning Threshold must be between 40 and 100 and always below the
corresponding Alarm Threshold�
87� R/W NV Warning Threshold
The following Alarm Threshold registers set the thresholds for the Alarms� A Alarm Threshold register is given
in percent of the Full Load registers (85 = 85%)� An Alarm will occur if the measured current is above the Alarm
Threshold for at least the Alarm Time Delay� Default for the Alarm thresholds is 80%� The Values that are
written to the Alarm Threshold must be between 50 and 100 and always above the corresponding Warning
Threshold�
88� R/W NV Alarm Threshold
