73 Installation & Operation Manual, GE Series DPB Busway
March 25, 2013, Rev 0 GE Confidential
Series DPB Busway Installation & Operation Manual
44� R Minimum Current, Phase 2C
45� R Minimum Current, Phase 2N
46� R Minimum Current, Phase 2G
47� R Minimum Current, Phases1A & 2A
48� R Minimum Current, Phases 1B & 2B
49� R Minimum Current, Phases 1C & 2C
These registers show the maximum phase currents and are in tenth of amps (100 = 10�0 Amps)
50�
R Maximum Current, Phase 1A
51� R Maximum Current, Phase 1B
52� R Maximum Current, Phase 1C
53� R Maximum Current, Phase 1N
54� R Maximum Current, Phase 1G
55� R Maximum Current, Phase 2A
56� R Maximum Current, Phase 2B
57� R Maximum Current, Phase 2C
58� R Maximum Current, Phase 2N
59� R Maximum Current, Phase 2G
60� R Maximum Current, Phases 1A & 2A
61� R Maximum Current, Phases 1B & 2B
62� R Maximum Current, Phases 1C & 2C
Writing this register will reset the current Min and Max registers to the current value�
63� W Min/Max Reset
These registers set the capacity of full load allowed for the alarms� Units are in Amps (125 = 125 Amps)� The
Values that are written must be between 100 and 650� The Default is 250 Amps
64�
R/W NV Full Load Side One
65� R/W NV Full Load Side Two
These registers show current demand per phase and are in tenth of amps (262 = 26�2 Amps)� Values are the
average current over the time given in the Demand Register�
66�
R Demand phase 1A
67� R Demand phase 1B
68� R Demand phase 1C
69� R Demand phase 2A
70� R Demand phase 2B
71� R Demand phase 2C
The Demand Register is time that the demand is averaged over in minutes� It must be between 10 to 60
minutes� The Default is 15 minutes�
72� R/W NV Demand time
These registers show Percent load and is given in tenth of a percent (753 = 75�3%)� These percents are the
Amps per phase divided by the full load of that side�
73�
R Percent load phase 1A
74� R Percent load phase 1B
75� R Percent load phase 1C
76� R Percent load phase 2A
77� R Percent load phase 2B
