Series DPB Busway Installation & Operation Manual
bit
15:
Under
Temperature
4
This register shows the setting for the Temperature and Current monitoring setup� A set bit indicated active value�
78�
R/W
NV
Current
Option
Setting
bit
0:
Flip
Current
for
Strip
1
bit
1:
Flip
Current
for
Strip
2
bit
2:
Temperature
in
Fahrenheit
bits 3 – 14: Not Used Always read as 0
bit
15
Current
Loss
These registers show the KW and are in hundredth of KW (500 = 5�00 KW)
79�
R KW,
Breaker
1A
80�
R KW,
Breaker
1B
81�
R KW,
Breaker
1C
82�
R KW,
Breaker
2A
83�
R KW,
Breaker
2B
84�
R
KW,
Breaker
2C
85�
R
KW, Breakers 1A & 2A
86�
R
KW, Breakers 1B & 2B
87�
R
KW, Breakers 1C & 2C
KVA Registers 88-96 are in hundredth of KVA (500 = 5�00 KVA)
88�
R KVA,
Breaker
1A
89�
R KVA,
Breaker
1B
90�
R KVA,
Breaker
1C
91�
R KVA,
Breaker
2A
92�
R KVA,
Breaker
2B
93�
R KVA,
Breaker
2C
94�
R
KVA, Breakers 1A & 2A
95�
R
KVA, Breakers 1B & 2B
96�
R
KVA, Breakers 1C & 2C
KVAR Registers 97-105 are in hundredth of KVAR (500 = 5�00 KVAR)
97�
R KVAR,
Breaker
1A
98�
R KVAR,
Breaker
1B
99�
R KVAR,
Breaker
1C
100�
R KVAR,
Breaker
2A
101�
R KVAR,
Breaker
2B
102�
R KVAR,
Breaker
2C
103�
R
KVAR, Breakers 1A & 2A
104�
R
KVAR, Breakers 1B & 2B
105�
R
KVAR, Breakers 1C & 2C
Power Factor Registers 106-114 are in hundredth of PF (98 = 0�98 PF)
106�
R Power
Factor,
Breaker
1A
107�
R Power
Factor,
Breaker
1B
108�
R Power
Factor,
Breaker
1C
109�
R Power
Factor,
Breaker
2A
110�
R Power
Factor,
Breaker
2B
111�
R Power
Factor,
Breaker
2C
112�
R
Power Factor, Breaker 1A & 2A
