Series DPB Busway Installation & Operation Manual
BCMS Basic = Current Only
BCMS Plus = Current + Voltage
PERSONALIZATION
PARAMETER
DESCRIPTION
RESOLUTION
NOTES
BCMS
BASIC
BCMS
PLUS
Circuit Breaker Size:
Source circuit breaker rating 1 A
Defines source circuit breaker
rating; default is 250 A (1 A incre-
ments); 50-600 A range
a
a
Warning Time Delay:
Time (seconds) before warn-
ing alarm activates
0-60 seconds
Defines duration current must
exceed threshold before activat-
ing a current default is 0 seconds
warning alarm;
a
a
Alarm Time Delay:
Time (seconds) before alarm
activates
0-60 seconds
Defines duration current must
exceed threshold before activating
a high current alarm; default is 10
seconds
a
a
Demand Average Time:
Time (seconds) to determine
average current
1 second
Defines time by which average
current is determined; default is 15
seconds; range is 15-60 seconds
a
a
Current Warning Alarm:
Circuit breaker current first
level alarm threshold
40-100%
Defines threshold based on a
percentage of circuit breaker rating
(default is 70%) to activate current
warning alarm after a time delay
(default is zero seconds).
a
a
Current High Alarm:
Circuit breaker current sec-
ond level alarm threshold
50-100%
Defines threshold based on a
percentage of circuit breaker rating
(default is 85%) to activate high
current alarm after a time delay
(default is 10 seconds).
a
a
Frequency:
Source frequency
0.1 Hz
Defines frequency (60 Hz or 50 Hz)
a
Board Name Personal-
ization
User defined device name
16 Char
Device name; 16 Character maxi-
mum
a
Overvoltage Alarm:
High voltage detected on
source
0.1V
Defines voltage to activate over
voltage alarm
a
Undervoltage Alarm:
Low voltage detected on
source
0.1V
Defines voltage to activate under
voltage alarm
a
