Installation & Operation Manual, GE Series DPB Busway
March 25, 2013, Rev 0
GE Confidential
Series DPB Busway Installation & Operation Manual
113�
R
Power Factor, Breaker 1B & 2B
114�
R
Power Factor, Breaker 1C & 2C
These registers are circuit Phase Kilowatt Hours per phase� Values are in kilowatts hours (90 = 90kwh) For
KWH 32-bit value multiply High-word integer by 2^16 (65536) and add Low-word integer�
115�
R
NV
KWH High-word integer, Breaker 1A
116�
R
NV
KWH Low-word integer, Breaker 1A
117�
R
NV
KWH High-word integer, Breaker 1B
118�
R
NV
KWH Low-word integer, Breaker 1B
119�
R
NV
KWH High-word integer, Breaker 1C
120�
R
NV
KWH Low-word integer, Breaker 1C
121�
R
NV
KWH High-word integer, Breaker 2A
122�
R
NV
KWH Low-word integer, Breaker 2A
123�
R
NV
KWH High-word integer, Breaker 2B
124�
R
NV
KWH Low-word integer, Breaker 2B
125�
R
NV
KWH High-word integer, Breaker 2C
126�
R
NV
KWH Low-word integer, Breaker 2C
127�
R
NV
KWH High-word integer, Breaker 1A & 2A
128�
R
NV
KWH Low-word integer, Breaker 1A & 2A
129�
R
NV
KWH High-word integer, Breaker 1B & 2B
130�
R
NV
KWH Low-word integer, Breaker 1B & 2B
131�
R
NV
KWH High-word integer, Breaker 1C & 2C
132.
R
NV
KWH Low-word integer, Breaker 1C & 2C
Writing this register will reset all KWH registers to zero�
133�
W
KWH
Reset
Bus connection temperature given in degrees Celsius (24 = 24 ºC) or Fahrenheit (75 = 75 ºF)�
134�
R Temperature
Board
135�
R Temperature
1
136�
R Temperature
2
137�
R Temperature
3
138�
R Temperature
4
139�
R Max
Temperature
Board
140�
R Max
Temperature
1
141�
R Max
Temperature
2
142�
R Max
Temperature
3
143.
R Max
Temperature
4
144.
R Min
Temperature
Board
145.
R Min
Temperature
1
146.
R Min
Temperature
2
147.
R Min
Temperature
3
148.
R Min
Temperature
4
This register gives the over temperature threshold for the board given in degrees Celsius (24 = 24 ºC) or
Fahrenheit (75 = 75 ºF)� Default for Temperature threshold for board is 80 ºC and for the Bus Temperature
thresholds is 120 ºC�
149�
R/W
Over
Temperature
threshold
150�
R/W
Under
Temperature
threshold
