Issue 3.1.B

Xedio Suite Version 3.1 – User’s Manual – CleanEdit

EVS Broadcast Equipment – January 2011


80

Zone Description

Scale Bar and
Move Bar

The Scale bar and Move bar allow the user to easily navigate
in the timeline.

See also the section 6.5.3 ‘Scale Bar and Move Bar’, on page
81.

TC and Duration
Fields

The timecode and duration fields provide time information on
the position of the mark IN, mark OUT, full edit duration, or
duration between marks.
See also the section 6.5.8 ‘Timecode and Duration Fields’, on
page 88.

Track Selection
and
Audio Settings

The buttons for track selection on the left of the track are
used to select:

the tracks to be taken into account in an editing operation

the audio output (and mode) in playout, rendering, and

export actions.

The buttons on the right of the track are used:

to define the audio routing for stereo tracks

to zoom the track, and perform fine tuning on the audio

tracks.

See also the section 6.5.9 ‘Audio Track Selection and
Settings in the Timeline
’, on page 89.

Editing
Commands

The Editing buttons allow the users to perform various editing
actions on the edit loaded.

See also the section 6.5.10 ‘Editing Buttons in the Timeline

Area’, on page 96.

6.5.2 T

IMECODE

B

AR

The timecode bar, located above the timeline display, displays a graduation of the
timecode in the timeline. The timecode of the first frame will start with the

timecode defined when the edit was created.

The most precise graduation is a graduation by frame, i.e. from frame 0 to 24 in
PAL, and from frame 0 to 29 in NTSC.

The timecode bar displays the tags (graphics) and the cue points (reference
marks). Right-clicking the timecode bar opens the contextual menu from which you

can define tags and cue points. For more information, refer to the sections 7.8
Cue Points’, on page 121 and 10.2 ‘Adding a Logo or Graphic’, on page 174.
