Issue 3.1.B

Xedio Suite Version 3.1 – User’s Manual – CleanEdit

EVS Broadcast Equipment – January 2011


186

Example with a light orange background with 50% opacity:

A

DDING

G

RAPHICS

Provided that the Enable Import Picture option has been enabled in Xedio
Manager (Software > Parameter Profiles > CleanEdit > Cg), an Import Picture

button is displayed at the bottom of the Text Properties tab.

1. Press the

button.

The KM Importer Dialog bow opens:

2. Press the Browse button to select the picture file (.tif) to import.

3. Associate a Media Class to the picture from the Media Class field
4. Press OK.

The picture is added to the Video Display:

Note that the picture cannot be moved or resized once imported.
