EVS Multicam Version 10.04 – Operating Manual
EVS Broadcast Equipment SA – January 2011
Issue
10.04.A
177
18. Hypermotion Mode
18.1 INTRODUCTION
18.1.1 D
EFINITION AND
L
ICENSE
C
ODE
Note
The hypermotion mode is a software option, which requires the license
code 20 being installed. For more information on the required license key,
contact the Support or Sales team.
The Hypermotion mode allows the server to control a hypermotion camera. Those
cameras record at a frame rate much higher than classical cameras. They use a
buffer of images recorded in a memory of the hypermotion camera. This sequence
can then be ingested via the standard SDI connection into the server. The
hypermotion camera is considered as a normal camera by the server.
18.1.2 A
CTIVATING THE
H
YPERMOTION
M
ODE
To be able to access the hypermotion mode, you need to ensure that:
•
You have the requested license code.
•
You have activated the Hypermotion parameter in the setup of the Remote, on
page 6.4, F1. See also the Multicam Configuration manual.
•
You have correctly selected the number of Remotes in the Main menu
according to the Remote mode defined in the setup of the Remote, on page
6.4, F3. See also the Tech Ref Software manual.
Depending on the selected Remote mode, you will control the Hypermotion
camera only, or the hypermotion camera and a PGM of the server.
18.1.3 A
CCESSING AND
L
EAVING THE
H
YPERMOTION
M
ODE
•
To access the Hypermotion menu, press SHIFT+D (HyperMo) in the operational
menu.
•
To leave the Hypermotion menu or switch to the PGM control, press again
SHIFT+D in the operational menu. In Hypermotion + LSM mode, the D’ key
displays LSM Mode.
