15. Target Mode
15.1 INTRODUCTION
Note
The Target mode is a software option, which requires the license code
114 being installed. For more information on the required license key,
contact the Support or Sales team.
The Target mode is not available on EVS servers working with 10-bit
codecs.
This software option enables the tracking of an object/action by use of a circle,
arrow, ellipse or rectangle 1 , focusing the attention on certain details. The user can
choose the size, color and thickness of the border as well as the darkness of the
background for a highlight feature. The addition of the Loop function allows the
operator to store this effect as a clip.
The facilities within this software package can be operated using the tablet and
the stylus, or a touch screen. Selected in the Setup menu, the normal pointing
device is the tablet, selecting F2 in page 6.2 will toggle between tablet / touch
screen (only when the touch screen is available). The touch screen must always
be connected to the RS422 port #6 and defined on page 7.2 (F6) of the Setup
menu.
1
In this chapter, we use the words “tracking object” to refer to the type of shape selected by the
operator (circle, arrow, ellipse or rectangle).
