Displayed letter Function
E erases unwanted portion of graphic. See also Section 0.
k / >k< keyer off / on. See also Section 0.
L calls the Library module where drawing, logos, …
can be saved.
C marks CUE OUT point on current clip
S plays back the c lip at slow motion speed. The speed of slow
motion is predefined in the PGM Speed item from the Setup
Menu (Page2 – F3)
P plays back the current clip at normal speed
The clip countdown displays the field time. This means that the countdown
matches the slow motion speed.
Note
Selecting C (clear) from the monitor enters the Clear menu and the DFC
menu. DFC menu allows you to select the brush color from a YUV color
palette
If working in network mode, painting can be performed on remote clips as well as
on local clips.
14.3 FUNCTION DESCRIPTION
Straight Line / Broken Line Drawing (L)
Select L on the Paint Mode monitor display. You will then be prompted to enter the
first point of the line.
Place the pen at the start point and press lightly. Then place the pen at the next
point and press lightly again. A straight line appears to connect these 2 points.
Repeat this as many times until the line is complete, then place the pen over the
“ESC” area in the top right corner of the OSD and press lightly. The system
automatically defaults back to freehand drawing mode.
Circle Drawing (O)
Select this menu to draw circles.
A menu allows you to choose between the following options:
• Set centre (default): A pointer appears on the screen to let you choose the
centre of the circle. The radius will be the one last used or the default one if
none has been defined before.
