15.2 CREATING A TARGET TRACK
Begin by selecting all the appropriate types of tracking object, their size, color,
etc.
15.2.1 S
ELECTING THE TYPE OF TRACKING OBJECT
The character on the left of the “T” letter on the 1 s t line of the OSD shows the
current object:
O (letter “o”) Indicates a circle (default option)
0 (zero) Indicates a ellipse
↓ / ↑ / → / ← Indicates an arrow
█ Indicates a rectangle
Z Indicates the zoom mode is active (circle only available in
this mode)
15.2.2 S
ELECTING
O
THER
P
ARAMETERS OF THE
T
RACKING
O
BJECT
T: Select the background shade (Transparency level)
E: Select the border thickness (Edge)
S: Select the size of the tracking object (Size)
C: Select the border color (Colour)
Note
To select the size of the tracking object when it is a rectangle or an
ellipse, click on S on the first line of the OSD. You must define the
position of 2 opposite corners of the rectangle (in case of an ellipse, you
must define the opposite corners of the rectangle the ellipse in enc losed
in). When these 2 corners are defined, the system draws the resulting
rectangle or ellipse. You can confirm by clicking on OK or clear the
screen by clicking on CLEAR and redefine a new shape.
