background image

Issue

10.04.A

EVS Multicam Version 10.04 – Operating Manual

EVS Broadcast Equipment SA – January 2011

8

6.

Operational

Block 2

PLAY

Initiates playback

NETWORK

Enters the XNet menu. (connect to other servers on the

network)

LAST CUE

Re-cues EVS server to previous cue point

GOTO TC

Allows timecode entry, with «F» keys

FAST JOG

Used with jog dial for rapid, manual re-cue. This mode is

automatically reset after PLAY/LIVE commands.

MARK

Used to enter re-usable cue point (256 cycling cues).

RECORD

Initiates “E2E” mode

RETURN

Inside a clip, allows the operator to return to the same

picture inside the record train, if it still exists.

PRV CTL

Enables/disables the Preview Control mode.

PAGE

Selects current clip page, from 1 to 10.

7.

LCD Display

Provides current status of system

2.2 LED COLOURS

A selected key lights red.
When a key lights green, it means a value in relation with this key exists.
For example: F1 to F0 keys

Green light means a clip has been stored in relation with the key.

Green flashing light means a clip is being created.

Red light means the clip associated to the key is playing or is ready to play.

Red flashing light means a clip is being deleted (in network mode)
