TOSHIBA
9 - 20
Parameter Explanations (cont'd)
Items 177, 186, 195, and 204, PATTERN GROUP # < 1
,
2
,
3 , or 4 > SPEED #0 - This parameter
determines which preset speed (preset speeds 1 through 15 programmed in Items 110-141) is the first
speed in the pattern group. Unlike the other speeds #1 - #7, speed #0 is not repeated when
PATTERN
GROUP # < 1
,
2
,
3 , or 4 > NUMBER OF CYCLES is greater than one. Set this parameter to "0" to skip this
speed.
Items 178, 187, 196, 205, PATTERN GROUP # < 1
,
2
,
3 , or 4 > SPEED #1 - This parameter determines
which preset speed (preset speeds 1 through 15 programmed in Items 110-141) is the next speed in the
pattern group. Speed #1 can be but does not have to be Preset Speed #1.
Items 179, 188, 197, 206, PATTERN GROUP # < 1
,
2
,
3 , or 4 > SPEED #2 - This parameter determines
which preset speed (preset speeds 1 through 15 programmed in Items 110-141) is the next speed in the
pattern group. Speed #2 can be but does not have to be Preset Speed #2.
Items 180, 189, 198, 207, PATTERN GROUP # < 1
,
2
,
3 , or 4 > SPEED #3 - This parameter determines
which preset speed (preset speeds 1 through 15 programmed in Items 110-141) is the next speed in the
pattern group. Speed #3 can be but does not have to be Preset Speed #3.
Items 181, 190, 199, 208, PATTERN GROUP # < 1
,
2
,
3 , or 4 > SPEED #4 - This parameter determines
which preset speed (preset speeds 1 through 15 programmed in Items 110-141) is the next speed in the
pattern group. Speed #4 can be but does not have to be Preset Speed #4.
Items 182, 191, 200, 209, PATTERN GROUP # < 1
,
2
,
3 , or 4 > SPEED #5 - This parameter determines
which preset speed (preset speeds 1 through 15 programmed in Items 110-141) is the next speed in the
pattern group. Speed #5 can be but does not have to be Preset Speed #5.
Items 183, 192, 201, 210, PATTERN GROUP # < 1
,
2
,
3 , or 4 > SPEED #6 - This parameter determines
which preset speed (preset speeds 1 through 15 programmed in Items 110-141) is the next speed in the
pattern group. Speed #6 can be but does not have to be Preset Speed #6.
Items 184, 193, 202, 211, PATTERN GROUP # < 1
,
2
,
3 , or 4 > SPEED #7 - This parameter determines
which preset speed (preset speeds 1 through 15 programmed in Items 110-141) is the next speed in the
pattern group. Speed #7 can be but does not have to be Preset Speed #7.
Items 185, 194, 203, 212, PATTERN GROUP # < 1
,
2
,
3 , or 4 > NUMBER OF CYCLES - This parameter
determines how many times the pattern group made up of speeds #1 through #7 entered in the above
parameters will be repeated.
Items 213, 215, 217, 219, 221, 223, 225, 227, 229, 231, 233, 235, 237, 239, and 241,
SPEED #
<
1
,
2
,
3
,
4
,
5
,
6
,
7
,
8
,
9
,
10
,
11
,
12
,
13
,
14
,or
15
>
CONTINUE MODE . This parameter affects the timing
of the speeds in a pattern group:
0: Preset speed's time is counted in seconds from the beginning of the run (accel/decel time is
included in the time entered in the following parameter,
SPEED
#
<
1
,
2
,
3
,
4
,
5
,
6
,
7
,
8
,
9
,
10
,
11
,
12
,
13
,
14
,or
15
>
DRIVE TIME
1: Preset speed's time is counted in minutes from the beginning of the run (accel/decel time is
included in the time entered in the following parameter, SPEED
#
<
1
,
2
,
3
,
4
,
5
,
6
,
7
,
8
,
9
,
10
,
11
,
12
,
13
,
14
,or
15
>
DRIVE TIME
2: Preset speed's time is counted in seconds after preset speed is reached (accel/decel time is
not included in the time entered in the following parameter, SPEED
#
<
1
,
2
,
3
,
4
,
5
,
6
,
7
,
8
,
9
,
10
,
11
,
12
,
13
,
14
,or
15
>
DRIVE TIME
3: Preset speed's time is counted in minutes after preset speed is reached (accel/decel time is
not included in the time entered in the following parameter, SPEED
#
<
1
,
2
,
3
,
4
,
5
,
6
,
7
,
8
,
9
,
10
,
11
,
12
,
13
,
14
,or
15
>
DRIVE TIME
4: Non-stop (stop by breaking ST-CC or F-CC or R-CC).
5: Drive waits for step command to change speeds. See Items 45-54 and setting value 19
on page 9-9.
