TOSHIBA
8 - 27
GROUP:AM/FM TERMINAL ADJUSTMENT PARAMETERS
PARAMETER
DESCRIPTION
LIQUID CRYSTAL DISPLAY ADJUSTMENT
RANGE
ITEM
NO.
PAGE
NO.
FACTORY
SETTING
FM TERMINAL FUNCTION 275 "FM" terminal signal selection 0: Pre-compensation 0 9-23
SELECTION ref frequency
1: Post-compensation
output frequency
2: Frequency
referencee
3: Output current
4: DC voltage
5: Output voltage
6: Torque current
7: Excitation current
8: PID feedback
value
9: Motor overload
ratio
10: Inverter overload
ratio
11: DBR overload
ratio
12: Input power
13:Output power
14: Meter calibration
(100% fixed output)
15: Peak output
current
16: Peak input voltage
FREQUENCY METER 276 "FM" terminal calibration - 0.0 Hz 9-24
ADJUSTMENT
AM TERMINAL FUNCTION 277 "AM" terminal signal selection 0: Pre-compensation 3 9-25
SELECTION reference
frequency
1: Post-
compensation
output frequency
2: Frequency setting
value
3: Output current
4: DC voltage
5: Output voltage
6: Torque current
7: Excitation current
8: PID feedback
value
9: Motor overload
ratio
10: Inverter overload
ratio
11: DBR overload
ratio
12: Input power
13: Output power
14: Meter calibration
(100% fixed output)
15: Peak output
current
16: Peak input voltage
CURRENT METER 278 "AM" terminal calibration - 0 % 9-25
ADJUSTMENT
