TOSHIBA
Standard Connection Diagrams (cont'd)
4 - 2
L1(R)
L2 (S)
L3 (T)
PROGRAMMABLE
SIGNAL INPUT
PROGRAMMABLE
ANALOG INPUT
R/CH-C
FLC
FLA
+
+
S1
PP
RR
AUTO
REF.
AUTO
REF.
-
-
T3 (W)
T1(U)
T2 (V)
PROGRAMMABLE
OUTPUT CONTACTS
250V, 2A MAX
PROGRAMMABLE
OUTPUT CONTACTS
250V, 2A MAX
AM FM
PROGRAMMABLE
SIGNAL OUTPUT
0-1mA or 4-20mA
M
M
R41/46
R40/44
R38
RJ
RES
F
R
ST
MCCB
CC
R/CH-A
LOW-A
LOW-C
P24
FP
FM
AM
CC
PULSE OUTPUT
50mA MAX
GND(E)
DIGITAL
OPERATION PANEL
CC
IV
RX
(see note 1 below) S4
+ +
FLB
S3
S2
NOTE:
1.) As an example, the "S4" terminal is shown above as an EMERGENCY OFF input. See
Section 8 for information on how to program the drive for this and other functions.
INPUT POWER SELECTION
415/460V-50/60Hz
400/440V-50/60Hz
380V-50Hz
INPUT POWER SUPPLY
(set by input power selection)
Potentiometer
TOSVERT-130H3
STANDARD CONNECTION
MODEL 4400 TO 430K
