Toshiba Adjustable Speed Drive H3 - Manual (Page 31)

TOSHIBA
LOCAL
REMOTE
Up scroll key used for incrementing numerical values. Also, when a parameter or
group name is displayed, the name of the previous parameter/group can be
displayed by pressing this key.
Down scroll key used for decrementing numerical values. Also, when a
parameter or group name is displayed, the name of the next parameter/group
can be displayed by pressing this key.
Used to start a run from the keypad (local control).
Key changes between the local control mode and the terminal block input
control mode operation. When the local control LED in the keypad is "on",
operation of the drive is from the keypad.
This key functions as the STOP key when running from keypad (local control). In
all other modes, emergency off is engaged when this key is pressed twice.
During a drive trip, the tripped state can be reset by pressing this key twice.
This key is used to enter the monitor mode..
This key is used to select or enter a parameter name, a parameter value, a
frequency command, or a group name.
This key is used to enter the programming mode.
6 - 2
Key Function
RUN
PRG
STOP
CLEAR
MON
READ
WRITE
Operating Panel Keys and Functions
The following chart explains each of the key functions on the keypad
Keys and Functions
