Toshiba Adjustable Speed Drive H3 - Manual (Page 54)

TOSHIBA
SPEED #1 CONTINUE 213 determines how speed time 0: Count in seconds 0 9-20
MODE is measured from time of
activation *
1: Count in minutes
from time of
activation *
2: Count in seconds
from time set
speed is reached *
3: Count in minutes.
from time set
speed is reached *
4: Non-stop
(continue until
STOP command)
5: Continue until next
step command
SPEED #1 DRIVE TIME 214* Speed #1 drive time 0 - 8000 1 sec./min. 0 9-21
SPEED #2 CONTINUE 215 Speed #2 drive continuation mode Same options as 0 9-20
MODE Item 213
SPEED #2 DRIVE TIME 216** Speed #2 drive time 0 - 8000 1 sec./min. 0 9-21
SPEED #3 CONTINUE 217 Speed #3 drive continuation mode Same options as 0 9-20
MODE Item 213
SPEED #3 DRIVE TIME 218*** Speed #3 drive time 0 - 8000 1 sec./min. 0 9-21
SPEED #4 CONTINUE 219 Speed #4 drive continuation mode Same options as 0 9-20
MODE Item 213
SPEED #4 DRIVE TIME 220 Speed #4 drive time 0 - 8000 1 sec./min. 0 9-21
****
SPEED #5 CONTINUE 221 Speed #5 drive continuation mode Same options as 0 9-20
MODE Item 213
SPEED #5 DRIVE TIME 222 Speed #5 drive time 0 - 8000 1 sec./min. 0 9-21
*****
8 - 19
GROUP:PATTERN RUN CONTROL PARAMETERS (cont'd)
PARAMETER
DESCRIPTION
LIQUID CRYSTAL DISPLAY ADJUSTMENT
RANGE
ITEM
NO.
PAGE
NO.
DISPLAY
RESOLUTION
FACTORY
SETTING
Table continued on next page
*Item 214 is available only when Item 213 Adjustment Range option 0 - 3 is selected.
**Item 216 is available only when Item 215 Adjustment Range option 0 - 3 is selected.
***Item 218 is available only when Item 217 Adjustment Range option 0 - 3 is selected.
****Item 220 is available only when Item 219 Adjustment Range option 0 - 3 is selected.
*****Item 222 is available only when Item 221 Adjustment Range option 0 - 3 is selected.
